File:ThrottleValve BronzeTeflon ModeltecMay1984-5.jpg
Jump to navigation
Jump to search
Size of this preview: 800 × 549 pixels. Other resolutions: 2,560 × 1,758 pixels | 3,592 × 2,466 pixels.
Original file (3,592 × 2,466 pixels, file size: 1.57 MB, MIME type: image/jpeg)
Summary
The throttle is shown three-quarters open. Attachment to the smokebox is by the use of a brass block, secured to the top of the throttle by 6-32 screws. The steel plate is attached to the mounting angle (riveted to the top of the smokebox) by the use of 5-40 screws. The mounting angle and location were part of the mounting to fasten the original throttle. Photo by Robert Maynard, Modeltec May 1984.
